Mooring Chock NS2587
● Type: closed mooring chock
● Material: cast steel
● Standard: NS2587
● Rope guiding mooring eye
Description
NS2587 mooring chock usually installed on the bulwark, used to limit the cable lead-out position. It is a closed-hole chock, circular or oval in shape, usually made of cast steel. follows the strict quality control system. It is designed as per the Norwegian Standard. Under this standard, there are four types of chocks available, such as NS2587 chocks, NS2588 chocks, NS2589 chocks, NS2590 chocks . The surface of the NS2587 chock is smooth without burs or sharp edges, which helps reduce the friction of the mooring rope. extending the service life of the cable.
For this chock, it has two optional nominal dimensions. Type A is welded, Type B is casted. We mainly produce type B.
The mooring chock has the certificate of CCS, DNV, GL, KR, LR, NK, etc.
Specification of Mooring chock NS2587
|
NS2587 chock (Type B) |
|||||
|
Nominal size |
c2 |
d2 |
e2 |
t2 |
Mass(kg) |
|
200*150 |
330 |
280 |
130 |
16 |
14.9 |
|
300*200 |
458 |
358 |
158 |
20 |
47 |
|
400*250 |
600 |
450 |
200 |
25 |
99 |
packing
