Semi Rotary Hand Pump For Oil Transfer
● Series: CYL
● Type: semi-rotary hand pump
● Capacity: 15~105l/min
● Head: 14~18m
Description
CYL semi-rotary hand pump is used for oil transfer, pumping water, gasoline, kerosene and on iron and copper and other non-corrosive liquid, do not apply to contain fibers or other solids in the liquid, the suction liquid temperature under 60 C.
CYL hand pump has the advantages of compact structure, elegant style, convenient and reliable use
Available for shipping
Model explanation CYL15
CYL-marine Semi-rotary hand pump
15-inlet and outlet diameter is 15mm
Main technical parameter
Type | Capacity (l/min) | Head (m) | Suction vacuum height (m) | Weight (kg) |
CYL-15 | 15 | 14 | 5 | 5 |
CYL-20 | 20 | 14 | 5 | 5.5 |
CYL-25 | 25 | 26 | 6 | 7.5 |
CYL-32 | 28 | 26 | 6 | 9 |
CYL-40 | 65 | 18 | 6.5 | 22.5 |
CYL-50 | 105 | 18 | 6.5 | 34.5 |
Note: Reciprocating times: 50times/min
