Marine JIS Standard 5K 10k Check Valve

Marine JIS standard check valve is produce according to Japan standard which made to stop the fluid non-return. It is very common used on ships. Our JIS standard 5K/10K marine check valve is made of bronze, cast iron or Cast steel, widely matched with flanged marine globe valve, seawater resistant marine angle valve and wafer butterfly valve for vessel ballast water system. All products pass CCS, ABS, BV, LR certification, complying with JIS and DIN industry standards for cargo ships, fishing boats and offshore engineering platforms. As a professional custom marine valve supplier, we support non-standard size customization according to clients' technical drawings.



JIS Check valve Features

Standard: JIS

Pressure: 5K, 10K, 16k, 20K

Size: DN10 ~ DN300

Body material: cast iron, cast steel, bronze, stainless steel

Certification: CCS, ABS, BV, RINA



Application

Ballast, bilge and cooling water pipeline of cargo ships, barges and fishing vessels;

Fuel & lube oil pipeline for main engine and auxiliary equipment;

Pipeline supporting system for offshore platform and marine engineering projects.



Specification of bronze material Swing check valve 5k

Material

Body	Bronze
Bonnet	Bronze or Bass
Disc	Bronze
Sear	Bronze
Stem	Brass
Handwheel	Cast iron



Technical Data

Manufactured in accordance to JIS F7400/ Flanges as per JIS B2220-5K



Dimensions

Code	Size	Face to Face(L)	Flange dia.(D)	Pitch(C)	Hole(n×d)	Weight
	mm	mm	mm	mm	Kgs	Kgs
751401	25	110	95	75	4×D12	2.24
751402	32	130	115	90	4×D15	3.07
751403	40	140	120	95	4×D12	4.34



For other material, pressure check valve please contact us

There are kinds of check valve for choose

1. Cast iron material

Marine Cast Iron Check Globe Valves JIS F7358 5k

Marine Cast Iron Screw Down Check Globe Valve JIS F7353 5K

Marine Cast Iron Screw Down Check Angle Valve JIS F7354 5K

Marine Cast Iron Screw Down Check Globe Valve JIS F7375 10K

Marine Cast Iron Screw Down Check Globe Valve JIS F7376 10K

Marine Cast Iron Screw Down Check Globe Valve JIS F7377 16K

Marine Cast Iron Screw Down Check Angle Valve JIS F7378 16k

Marine Cast Iron Swing Check Valve JIS F7373 10K

Cast iron swing check valve 10K

2. Cast steel material

Marine Cast Steel Screw Down Check Globe Valve JIS F7311C 5K

Marine Cast Steel Screw Down Check Angle Valve JIS F7312C 5K

Marine Cast Steel Screw Down Check Globe Valve JIS F7473 20K

Marine Cast Steel Screw Down Check Angle Valves JIS F7474 20K

Marine Cast Steel Screw Down Check Globe Valve F7471 10K

Marine Cast Steel Screw Down Check Angle Valve JIS F7472 10K



3. Bronze material

Marine Swing Check Valve JIS F7371 5K

Marine Bronze Screw-down Check Globe Valve JIS F7352 5K

Marine Bronze Screw-down Check Globe Valve JIS F7409 16K







Other standard check valve also available



ANSI standard check valve

Others JIS standard we can provide
