50kg 100kg Light Weight Admiralty Anchor

Name: 50kg 100kg Light Weight Admiralty Anchor
Brand: Nicee
SKU: 156482438

● Type: stock anchor
● Anchor weight: 50KG to 10000KG
● Material: casting steel
● Finishing: black painting, hot dip galvanized

Send Inquiry

Description

The Admiralty anchor is a kind of stock anchor, consists of a central shank with a ring or shackle for attaching the rode (the rope, chain, or cable connecting the ship and the anchor). At the other end of the shank there are two arms, carrying the flukes, while the stock is mounted to the shackle end, at ninety degrees to the arms. When the anchor lands on the bottom, it will generally fall over with the arms parallel to the seabed. As a strain comes onto the rode, the stock will dig into the bottom, canting the anchor until one of the flukes catches and digs into the bottom.

Features:

● Name: 50kg 100 kg light weight Admiralty anchor

● Anchor weight: 50KG to 10000KG

● Material: casting steel

● Finishing: black painting, hot dip galvanized

● Certificate: DNV-GL, BV, LRS, ABS, RINA, IRS, RS, CCS

100kg admiralty anchor

Nominal Weight	Size(mm)
(KG)	H	h	h1	B	C
50	960	230	42	635	185
75	1105	266	45	710	210
100	1215	296	49	780	230
125	1310	316	52	840	245
150	1395	336	55	900	265
200	1535	370	61	990	290
250	1650	398	65	1065	310
300	1755	423	70	1105	330
400	1930	465	77	1240	365
500	2080	502	84	1335	390
600	2210	533	89	1440	415
700	2330	560	93	1500	440
800	2435	587	97	1570	460
900	2530	610	101	1630	475
1000	2620	611	104	1685	495
1250	2825	680	112	1810	535
1500	3000	725	118	1955	565
2000	3300	797	131	2140	625
2500	3550	857	138	2270	672
3000	3780	912	150	2415	715
3500	3980	960	158	2540	750
4000	4160	1000	155	2650	785
5000	4480	1100	184	2830	800
6000	4740	1113	190	3000	438
7000	5025	1180	200	3165	960
8000	5240	1280	210	3300	980
9000	5450	1330	220	3440	990
10000	5680	1340	230	3600	1085
